Technobeam
®
User Manual Index-i
A
Accessories ..................................1-5
Addr Lost .................................... 2-25
Address menu (ADDR) ................ 3-10
Aligning LAD ..................6-19 to 6-25
Anti-reflective glass ................... 6-16
Aperture ring ................................6-8
Arc lamp ................................. intro-2
B
Beam angle, setting ........1-12 to 1-14
Beam angles ............................... 1-14
Boot Diff ..................................... 2-25
C
Cabling
constructing ...........................2-5
terminators ............................2-5
Capturing presets ......................4-11
C-clamps
ordering .................................1-5
using ....................................2-10
Channel range ............................2-16
assigning .............................. 2-15
overlapping ..........................2-16
Chase ............................................4-2
Cleaning fixture .............6-15 to 6-18
Coated side of dichroic ................6-6
Construct .....................................4-2
Constructing cabling ....................2-5
Control method
changing (CHNL) ..................3-13
selecting .............................. 2-14
Controlling Laser Aiming Device . 5-5
Crossload ...................................3-19
Crossloading ..............................2-19
Custom lithos .............................6-11
Customer Service ...................intro-4
D
Dichroics
coated side .............................6-6
replacing ..................... 6-5 to 6-7
Dimensions .................................. 1-2
Display ....................................... 2-13
DMX 512
cabling ....................................2-4
cabling specifications ............1-5
constructing cabling ..............2-5
control commands not
accepted .............................. 2-22
explanation ............................2-4
fixture number conversion . A-16
linking devices .......................2-7
setting up link ............. 2-6 to 2-8
terminator ..............................2-5
troubleshooting ................... 2-24
DMX 512 protocol
Technobeam ................A-3 to A-7
Technobeam-i ............A-7 to A-12
DMX channel range .................... 2-15
DMX start channel ..................... 2-14
determining ......................... 2-16
DMX start channel control
method ...................................... 2-14
DMX wasted channels ................ 2-17
Down arrow key ........................... 3-2
E
Effects, replacing ............. 6-7 to 6-11
EIA RS-485 ................................... 2-5
Electrical specifications ............... 1-2
EMEM
CHNL ................................... 2-26
DPLY .................................... 2-26
FHRS .................................... 2-26
L/ST ..................................... 2-26
LENS .................................... 2-26
LHRS .................................... 2-26
MODE ................................... 2-26
