PREDATOR XS TURNTABLE STRETCH WRAPPER OPERATION MANUAL
HIGHLIGHT INDUSTRIES, INC. ● 2694 PRAIRIE SW; WYOMING; MI 49519 ● 1-800-531-2465
I-2
Film Delivery System
• ¼ HP 3-phase AC motor, ½ HP AC frequency drive
• Adjustable film force
• 200% / 250% average pre-stretch level
• 10” diameter roll capacity
• 20” height roll capacity
• OPTIONAL pre-stretch ratio of 230% / 300%
Requirements:
Part Number Description Number of Teeth
301339 Drive Gear 17
301340 Lower Fixed Gear 46
301341 Upper Fixed Gear 42
301342 Slip Gear 46/42
Actual measured pre-stretch level may vary depending on film type
(thickness) and film force applied to the load.
