PREDATOR XS TURNTABLE STRETCH WRAPPER OPERATION MANUAL
HIGHLIGHT INDUSTRIES, INC. ● 2694 PRAIRIE SW; WYOMING; MI 49519 ● 1-800-531-2465
VI-7
Tower Part List
No. Sub No. Part Number Description Quantity
1 600091 TOWER COVER WELDMENT 1
2 200090 SHCS, M10 x 25L 4
3 300774 GEARMOTOR, CARRIAGE LIFT 1
4 300775 SPROCKET, DRIVEN 1
5 300776 BRACKET, GEARMOTOR SUPPORT 1
6 300020 BEARING, 6202-NR 1
7 200631 SHCS, M5 x 8L 4
8 500466 BRACKET, LIMIT TRIP 2
9 600092 TOWER WELDMENT, 80” 1
10 500467 BRACKET, E-CHAIN MOUNT 1
11 300777 E-CHAIN 1
12 500468 COVER PLATE, 80” TOWER 1
13 200630 HHCS, M12 x 35L 2
14 200140 NUT M12 2
15 200090 SHCS, M10 x 25L 6
16 200632 THREADED ROD, M10 x 60L 2
17 500469 SHAFT, IDLER SPROCKET 1
18 300778 SPROCKET, IDLER 1
19 300017 BEARING 6002ZZ 1
20 300008 SNAP RING, 15mm EXTERNAL 2
21 200084 SHCS, M8 x 20L 1
22 300029 CHAIN 1
23 700063 CHAIN ATTACHMENT ASSEMBLY
W CHAIN TENSION SHAFT
X WASHER, M12
Y CHAIN ADJUST SEAT
Z NUT M12
27 500470 BRACKET, CARRIAGE LIFT 1
28 600093 CARRIAGE TROLLEY WELDMENT 1
29 500471 GUIDE WHEEL SHAFT 3
30 500472 SPACER, INNER 6
31 500473 GUIDE WHEEL 6
32 305300 BEARING, 6203 6
33 500474 SPACER, OUTER 6
NOTE
Although all parts are shown in the part list, some may not be available
individually. Selected parts must be purchased in assembly.
Parts available in inventory are highlighted. Non-highlighted parts may
have longer lead times.
