Highlight PREDATOR XS - System Overview Prints

PREDATOR XS TURNTABLE STRETCH WRAPPER OPERATION MANUAL
HIGHLIGHT INDUSTRIES, INC. ● 2694 PRAIRIE SW; WYOMING; MI 49519 ● 1-800-531-2465
I-3
SYSTEM
SYSTEMSYSTEM
SYSTEM OVERVIEW PRINT
OVERVIEW PRINT OVERVIEW PRINT
OVERVIEW PRINTS
SS
S
Exhibit 1-1: Predator XS Low Profile Overview Layout
NOTE
Shown below are STANDARD assembly drawings. It may not reflect
your purchased system, especially when optional items are added.
Refer to assembly drawings shipped inside the electrical enclosure for
more detail information.
