PREDATOR XS TURNTABLE STRETCH WRAPPER OPERATION MANUAL
HIGHLIGHT INDUSTRIES, INC. ● 2694 PRAIRIE SW; WYOMING; MI 49519 ● 1-800-531-2465
I-1
SYSTEM SPECIFICATIONS
SYSTEM SPECIFICATIONSSYSTEM SPECIFICATIONS
SYSTEM SPECIFICATIONS
Machine Dimensions
Low Profile High Profile
Length (inch) 116 121
Width (inch) 65 88
Height (inch) 92 93
Turntable Diameter (inch) 65
48 Octagon
(58 Diagonal)
Turntable Height from Floor (inch) 3 ¼ 13 ½
Wrapping Height (inch) 80 70
Operation Space (inch) 125 x 70 x 100
Maximum Load Size (inch) 56 x 56 x 80
Approximate Shipping Weight (lbs) 1220 1500
Electrical Specifications
• 120 VAC, 60 Hz, Single-phase, 15 AMP
• NEMA-12 rated electrical panel
• Operating temperature: +32°F to +110°F
• Lockable disconnect switch
• JIC wiring standard
• Programmable Logic Controller (PLC) with input/output diagnostic lights
Turntable System
• Low Profile: ½ HP 3-phase AC motor, ½ HP AC frequency drive
• High Profile: ¾ or 1 HP 3-phase AC motor, 1 HP AC frequency drive
• 20-30 loads per hour (spiral)
• 12 RPM turntable maximum speed
• 4,000 lbs turntable maximum load capacity
Film Carriage/Elevator System
• ½ HP 3-phase AC motor, ½ HP AC frequency drive
• Adjustable raise and lower speeds
• Automatic height detection photoelectric sensor
