PREDATOR XS TURNTABLE STRETCH WRAPPER OPERATION MANUAL
HIGHLIGHT INDUSTRIES, INC. ● 2694 PRAIRIE SW; WYOMING; MI 49519 ● 1-800-531-2465
VI-14
Control Box Part List
No. Sub No. Part Number Description Quantity
1 600152 SUPPORT BRACKET 2
2 600153 MOUNT BRACKET 2
3 200086 SHCS, M8 x 40L 8
4 600154 ELECTRICAL BOX 1
5 500106 HINGE 2
6 500479 SUBPANEL 1
7 300048 LOCK PLATE 2
8 600155 ELECTRICAL BOX DOOR 1
9 300041 LOCK, W/ KEY 2
10 200124 PHILLIPS SCREW, M4 x 25L 1
11 500080 KEY, SAFETY SWITCH 1
12 500016 SPRING 2
13 200788 NUT, NYLOC, M4 2
14 200106 MACHINE SCREW, M4 x 35L 4
15 400644 SAFETY SWITCH 1
16 200101 MACHINE SCREW, M4 x 12L 2
17 500105 SECURITY SWITCH BRACKET 1
NOTE
Although all parts are shown in the part list, some may not be available
individually. Selected parts must be purchased in assembly.
Parts available in inventory are highlighted. Non-highlighted parts may
have longer lead times.
