PREDATOR XS TURNTABLE STRETCH WRAPPER OPERATION MANUAL
HIGHLIGHT INDUSTRIES, INC. ● 2694 PRAIRIE SW; WYOMING; MI 49519 ● 1-800-531-2465
VII-1
RECOMMENDED SPARE PARTS
RECOMMENDED SPARE PARTSRECOMMENDED SPARE PARTS
RECOMMENDED SPARE PARTS
The table below lists the recommended spare parts.
Part Number Description Quantity
300772 DRIVE BELT, 154” 1
403556 T.T. HOME & STRETCH % PROX. 1
700060 T.T. CAM FOLLOWER ASS’Y 6
408117 DANCER BAR POTENTIOMETER 1
400637 CARRIAGE SAFETY LIMIT SWITCH 1
400639 CARR. UPPER/LOWER LIMIT SWITCH 1
300719 AUTO PUNCTURE SOLENOID 1
400643 LOAD HT. DETECTION PHOTO EYE 1
400644 CONTROL BOX SAFETY SWITCH 1
500080 CONTROL BOX SAFETY KEY 1
400618 SELECTOR SWITCH, 2 POSITION 1
400619 SELECTOR SWITCH, 3 POSITION 1
400620 POTENTIOMETER KNOB 1
400649 POTENTIOMETER, 5K 1
400613 E. STOP SWITCH 1
400621 MAIN DISCONNECT SWITCH 1
400658 FILM FEED CONTROLLER CARD 1
403172 CONTACTOR 1
403481 AC DRIVE, ½ HP, HITACHI 1
