Highlight PREDATOR XS - Film Carriage;Elevator Part List

PREDATOR XS TURNTABLE STRETCH WRAPPER OPERATION MANUAL
HIGHLIGHT INDUSTRIES, INC. ● 2694 PRAIRIE SW; WYOMING; MI 49519 ● 1-800-531-2465
VI-10
Film Carriage/Elevator Part List
No. Sub No. Part Number Description Quantity
1 600095 STRETCH KNOB COVER 1
2 200636 WING NUT, M5 x 12L 2
3 200766 MACHINE SCREW, M4 x 50L 4
4 500661 STRETCH KNOB HALF 2
5 500662 GEAR PULL ADAPTER 1
6 500663 GEAR POSITIONING SHAFT 1
7 301346 SLIP GEAR, 47T/44T, 200% / 250% 1
8 301365 SPRING 2
9 500684 SAFETY BUTTON 1
10 301345 FIXED GEAR 41T, 200% / 250% 1
11 301344 FIXED GEAR 44T, 200% / 250% 1
12 300807 BEARING, 6003ZZ 2
13 500685 FIXED GEAR SHAFT 1
13a 300017 SNAP RING, STW-17, 17mm Ext. 2
14 500686 BEARING SEAT 1
14a 301842 SNAP RING, RTW-35, 35mm INT. 2
14b 200802 SHCS, M6 x 16L & S.W & W 4
15 200633 SHCS, M6 x 10L 3
16 600096 CARRIAGE TOP COVER 1
17 500674 CARRIAGE COVER BRACKET 3
18 500047 SPRING 2
19 500673 SPRING SEAT 2
20 500019 SPROCKET, 17T 1
21 300846 CHAIN, inc. MASTER 1
22 204833 SHCS, M8 x 30L 4
23 408117 POTENTIOMETER, 5K 1
24 500675 POTENTIOMETER BRACKET 1
25 200635 MACHINE SCREW, M5 x 45L 1
26 600160 POTENTIOMETER ARM 1
27 500671 CARRIAGE TOP PAN 1
28 301358 GEARMOTOR, SV-A10 1
29 200078 SHCS, M6 x 16L 2
30 500669 LIMIT SWITCH BRACE 1
31 500672 LIMIT SWITCH MNT BRACKET 1
NO
TE
Although all parts are shown in the part list, some may not be available
individually. Selected parts must be purchased in assembly.
Parts available in inventory are highlighted. Non-highlighted parts may
have longer lead times.
