PREDATOR XS TURNTABLE STRETCH WRAPPER OPERATION MANUAL
HIGHLIGHT INDUSTRIES, INC. ● 2694 PRAIRIE SW; WYOMING; MI 49519 ● 1-800-531-2465
VI-11
32 400637 LIMIT SWITCH, TZ-7110 1
33 200106 MACHINE SCREW, M4 x 35 2
34 301343 GEAR, DRIVE, 19T, 200% / 250% 1
35 301359 SPROCKET, 12T 1
36 500670 PROX MOUNT BRACKET 1
37 403556 PROXIMITY SENSOR, PM12-04N 1
38 700074 DANCER STOP ASSEMBLY 2
U PLATE
V PIN, 4MM x 16L
W SPRING
X SET SCREW, M6 x 10L
Y BLOCK
Z RING
42 700479 DANCER BAR ASSEMBLY 1
V RING
W 301369 BEARING HK 1010
X SWINGING BAR SHAFT
Y DANCER BAR ARM
Z DANCER BAR ROLLER ASSEMBLY
47 500689 SUPPORT BRACKET 1
48 700466 FILM HOLDER ASSEMBLY 1
O 300026 BEARING, NTB1730
P 200078 SHCS, M6 x 16L
Q 500474 THRUST BUSHING,UPPER
R FILM CORE HOLDER (UPPER)
S THRUST BUSHING, LOWER
T FILM HOLDER SHAFT
U CLAMP COLLAR
V SPRING SEAT
W 500113 SPRING
X FILM CORE HOLDER (LOWER)
Y 500694 BRAKE DISC
Z 500695 FRICTION SEAT
60 700476 ROLLER ASS’Y, REAR 1
61 500664 LIMIT SWITCH MOUNT BRACKET 1
62 400639 LIMIT SWITCH, TZ-8108 2
63 600665 CARRIAGE PLATE, REAR 1
64 500666 ACRYLIC COVER 1
65 600159 TERMINAL COVER 1
66 500698 SPACER, SMALL 2
67 700481 BEARING SEAT ASSEMBLY 4
X SNAP RING, 42mm, INTERNAL
Y BEARING
Z BEARING SEAT
70 500700 PROTECTION RING 1
71 600098 PRE-STRETCH ROLLER, LARGE 1
