PREDATOR XS TURNTABLE STRETCH WRAPPER OPERATION MANUAL
HIGHLIGHT INDUSTRIES, INC. ● 2694 PRAIRIE SW; WYOMING; MI 49519 ● 1-800-531-2465
VI-12
72 300009 SNAP RING, 17mm, EXTERNAL 2
73 500699 SPACER, LARGE 1
74 600099 PRE-STRETCH ROLLER, SMALL 1
75 600173 CARRIAGE FRAME 1
76 500677 SENSOR PLUNGER 1
77 500678 SECURITY PAN SHAFT 1
78 600097 FOOT SECURITY PAN 1
79 200084 SHCS, M8 x 20L 1
80 301360 HINGE, CARRIAGE DOOR 2
81 200078 SHCS, M6 x 16L 1
82 500676 SAFE PLATE 1
83 301363 LINEAR BUSHING 1
84 500669 LIMIT SWITCH BRACE 2
85 400637 LIMIT SWITCH, TZ-7110 2
86 500048 BLOCK 2
87 700505 ROLLER ASS’Y 1
88 200851 MACHINE SCREW, M4 x 10L 4
89 600176 PUNCTURE SOLENOID COVER BRACKET 1
90 300719 PUNCTURE SOLENOID 24 VDC, TAU-1585 1
91 300720 PUNCTURE TIP 1
92 500761 PUNCTURE GUARD 1
97 700474 ROLLER ASS’Y, DOOR – OUTER 2
98 500762 SENSOR MOUNT TRACK 1
99 400643 PHOTO SENSOR, A3R-2MX 1
100 500764 PHOTO EYE BRACKET 1
101 700506 HANDLE, PHOTO EYE BRACKET 1
102 500763 PHOTO SENSOR SLIDE PLATE 1
103 600175 CARRIAGE DOOR 1
104 301364 SPRING 1
105 500682 DOOR LOCK BOLT 1
106 700475 ROLLER ASS’Y, DOOR – INNER 1
107 500683 LOCK MOUNT PLATE 1
108 200634 FHCS, M6 x 10L 1
109 500057 SECURITY KEY 1
110 500667 HANDLE BAR 1
111 301361 KNOB, DOOR LOCK 1
112 500765 CLUTCH ROLLER MOUNT 2
113 301369 CLUTCH BEARING, UPPER 1
114 700507 CLUTCH ROLLER 1
115 301370 CLUTCHING BEARING, LOWER 1
116 500760 ROLLER BRACKET 2
117 301814 SPRING, FOOT SECURITY PAN RETURN 1
