PREDATOR XS TURNTABLE STRETCH WRAPPER OPERATION MANUAL
HIGHLIGHT INDUSTRIES, INC. ● 2694 PRAIRIE SW; WYOMING; MI 49519 ● 1-800-531-2465
VI-2
Turntable Frame Parts List
No. Sub No. Part Number Description Quantity
1 200627 FHCS, M10 x 20L 4
2 500460 TURNTABLE TOP, 65” DIA (1.65M) 1
3 300772 BELT, 154” 1
4 500752 CENTER PULLEY, NEW STYLE 1
5 303703 THRUST BEARING, BELT PULLEY 1
6 700058 KING POST ASSEMBLY 1
U SNAP RING, 42mm INTERNAL
V CENTER SHAFT, BELT PULLEY
W BEARING, 6004ZZ
X SNAP RING, 42mm INTERNAL
Y BEARING SEAT, BELT PULLEY
10 200078 SHCS, M6 x 16L 4
11 500461 SENSOR SEAT 1
12 403556 PROXIMITY SENSOR, (PM12-04N) 1
13 500462.2 BRACKET, PROX DETECTION 1
14 700060 CAM FOLLOWER ASSEMBLY 14
W SNAP RING, 17mm EXTERNAL
X SHAFT , FOR CAM FOLLOWER
Y PLASTIC HOUSING, FOR CAM FOLLOWER
Z BEARING, 6203ZZ
18 700601 BELT RETURN ROLLER ASSEMBLY 1
W SNAP RING, 17mm EXTERNAL
X BELT IDLER PULLEY
Y BEARING, 6203ZZ
Z SHAFT, BELT PULLEY
22 200628 HEX HEAD TAP BOLT, M10 x 60L 1
23 200629 HHCS, M10 x 35L 4
24 300773 GEARMOTOR, TURNTABLE DRIVE 1
25 600088 MOTOR COVER (BOX) WELDMENT 1
26 500463 MOTOR BOX COVER PLATE 1
27 200851 PAN HEAD MACHINE SCREW, M4 x 10L 4
28 500464 PULLEY, TURNTABLE MOTOR DRIVE 1
29 600089 FIXED NUT WELDMENT 2
Although all parts are shown in the part list, some may not be available
individually. Selected parts must be purchased in assembly.
Parts available in inventory are highlighted. Non-highlighted parts may
have longer lead times.
