Highlight PREDATOR XS - Optional High Profile Turntable Frame Parts List

PREDATOR XS TURNTABLE STRETCH WRAPPER OPERATION MANUAL
HIGHLIGHT INDUSTRIES, INC. ● 2694 PRAIRIE SW; WYOMING; MI 49519 ● 1-800-531-2465
VI-5
OPTIONAL High Profile Turntable Frame Parts List
No. Sub No. Part Number Description Quantity
1 600094 Frame Weldment 1
2 645414 Pivot Brace Weldment 1
3 535492.2 Support Bracket 2
4 525027 Drive Shaft, 1-3/16” Dia. 1
6 645944 Reducer Bolt Plate Weldment 2
7 305163 Swivel Caster 2
8 305024.2 Drive Caster 1
9 300506 Bearing, 2-Bolt Flange, 1-3/16” 3
10 645384 Proximity Sensor Trip Weldment 1
11 301021 Gearmotor, ¾ HP, 28.59:1 1
12 403061 Proximity Sensor, NPN 1
13 300505 Sprocket, 60BS16 x 1-3/16” Bore 1
14 305684 Sprocket, 60BS16 x 1” Bore 1
15 305171 Chain, #60-1 2’
16 305176 Master Link, #60-1 1
17 200277 Nut, Jam, Nyloc, 1” 1
N/S 535237.2 Tilt Bracket (110” Tower Only) 1
NOTE
Although all parts are shown in the part list, some may not be available
individually. Selected parts must be purchased in assembly.
Parts available in inventory are highlighted. Non-highlighted parts may
have longer lead times.
