PREDATOR XS TURNTABLE STRETCH WRAPPER OPERATION MANUAL
HIGHLIGHT INDUSTRIES, INC. ● 2694 PRAIRIE SW; WYOMING; MI 49519 ● 1-800-531-2465
VI-28
Electrical Part List
No.
Sub No. Part Number Description Quantity
1a 400610 Auto RUN GREEN LAMP ~ BASE 1
1b 400611 Auto RUN GREEN LAMP ~ LAMP 1
1c 400609 Auto RUN GREEN LAMP ~ COVER 1
2 400608 POWER LAMP 1
3 400618 SELECTOR SWITCH, 2 POSITION 1
4 400615 CONTACT BLOCK, 1x NO 1
5 400619 SELECTOR SWITCH, 3 POSITION 4
6 400617 CONTACT BLOCK, 2x NO 4
7 400620 KNOB (BLACK) 3
8 400649 POTENTIOMETER, 5K 3
9 400613 EMERGENCY SWITCH 1
10 400616 CONTACT BLOCK, 1x NC 1
11 400621 DISCONNECT SWITCH 1
12 400614 CONTACT BLOCK, 1x NO 1
14 403557 TRANSFORMER, TR-80VA 1
15 403172 CONTACTOR 2
16 403561 BREAKER, C60A2PC16A 1
17 400658 FILM FEED CONTROLLER 1
18 500080 KEY FOR SAFETY SWITCH 1
19 403481 AC DRIVE, ½ HP, HITACHI 3
20 403103 PLC, A-B MICROLOGIX 1
21 403563 TERMINAL POST 1
22 403564 POWER SUPPLY, S-35-24 1
23 403565 AUX. CONTACT BLOCK 1
24 400630 RELAY LY2, DC24V 1
25 400628 RELAY BASE, LY2, PTF-08A 1
26 400607 TERMINAL STRIP, TB6P 1
27 400644 SECURITY SWITCH XCSPA791 1
28 403556 PROX SENSOR PM12-04N 2
29 403566 STRETCH % INDICATOR BOARD 1
30 400643 PHOTO SENSOR, A3R-2MX 1
31 400639 LIMIT SWITCH, TZ-8108 2
32 400637 LIMIT SWITCH, TZ-7110 3
34 300719 SOLENOID (TAU-1585 DC24V) 1
Although all parts are shown in the part list, some may not be available
individually. Selected parts must be purchased in assembly.
Parts available in inventory are highlighted. Non-highlighted parts may
have longer lead times.
