User Manual of DS-7200/7300/8100-SH Series DVR
121
8.6).
Figure 8.9 Set Arming Schedule of Alarm Input
6. If necessary, select PTZ Linking tab and set PTZ linkage of the alarm input.
Set PTZ linking parameters and click Apply to save the settings. Click OK to complete the settings of
the alarm input.
Note: Please check whether the PTZ or speed dome supports PTZ linkage.
One alarm input can trigger presets, patrol or pattern of more than one channel. But presets, patrols and
patterns are exclusive.
Figure 8.10 Set PTZ Linking of Alarm Input
7. If you want to set the alarm response actions of another alarm input, repeat the above steps or just copy
the above settings to it by clicking Copy in Alarm Input Settings interface.
