User Manual of DS-7200/7300/8100-SH Series DVR
87
Check the checkboxes to select the channel(s), and then the video from the selected channels will be played
back synchronously. Up to 16 channels can be set for synchronous playback.
Click the Max. Camera for Playback tab, and you can play back the video from 16 channels at a time.
Click the Min. Camera for Playback tab, and you can play back the video from only one channel.
Dates marked in different colors:
No record files in this day.
There is record file(s) in this day (not current day).
There is only event recording file(s) in this day (not current day).
Mouse cursor is located.
Figure 6.4 Toolbar of All-day Playback
Table 6.1 Detailed Explanation of All-day-playback Toolbar
Notes:
Playback progress bar: use the mouse to click any point of the progress bar or drag the progress bar to
locate special frames.
About video type bar: represents normal recording (manual or schedule); represents event
recording; represents smart search recording.
6.1.2 Playing Back by Time
Purpose:
Play back video files recorded in specified time duration. Multi-channel simultaneous playback and channel
switch are supported.
Steps:
1. Enter playback interface.
Menu>Playback
2. Check checkbox of channel(s) in the channel list.
3. Double-click to select a date on the calendar to play back the record file.
Note: If there are record files for that camera in that day, in the calendar, the icon for that day is
To Next Page
