HIKVISION DS-7200 Series User Manual

User Manual of DS-7200/7300/8100 Series DVR
30
9
HDMI
HDMI video output.
10
USB Interface
Connects USB mouse or USB flash memory devices.
11
LAN1/LAN2 Interface
2 RJ45 10M/100M/1000M Ethernet interfaces.
12
eSATA
Connects external SATA HDD, DVD-R/W.
13
Termination Switch
RS-485 termination switch. Up position is not terminated.
Down is terminated with 120Ω resistance.
14
RS-485 Interface
Connector for RS-485 devices. Connect the T+ and T- terminals to the R+
and R- terminals of PTZ receiver respectively.
KB
Connect the D+ and D- terminals to Ta and Tb terminals of the controller.
For cascading devices, the first DVR’s D+ and D- terminals should be
connected with the D+ and D- terminals of the next DVR.
15
Alarm In/Out
Connector for alarm input/output.
16
GND
Ground(needs to be connected when DVR starts up)
17
100~240VAC
100~240VAC power supply.
18
POWER
Switch for turning on/off the device.

HIKVISION DS-7200 Series Specifications

General

Brand	HIKVISION
Model	DS-7200 Series
Category	DVR
Language	English
