HIKVISION DS-7216HGHI-K1 User Manual

Network Video Recorder User Manual
14
System Operation ............................................................................................................. 58
Log out..................................................................................................................... 58
Shut Down the Device ............................................................................................. 58
Reboot the Device ................................................................................................... 58
Chapter 3 Camera Management ................................................................................................... 60
Add the IP Cameras .......................................................................................................... 60
Add the IP Camera Manually .................................................................................. 60
Add the Automatically Searched Online IP Cameras .............................................. 61
Connecting PoC Cameras ........................................................................................ 61
Configure Signal Input Channel ............................................................................... 62
Configuring 5 MP Long Distance Transmission ....................................................... 63
Enable the H.265 Stream Access ...................................................................................... 64
Upgrade the IP Camera .................................................................................................... 64
Chapter 4 Camera Settings ............................................................................................................ 66
Configure OSD Settings ................................................................................................... 66
Configure Privacy Mask .................................................................................................... 67
Configure the Video Parameters ...................................................................................... 68
Configure the Day/Night Switch ....................................................................................... 68
Configure Other Camera Parameters ............................................................................... 69
Chapter 5 Live View ....................................................................................................................... 70
Start Live View .................................................................................................................. 70
Digital Zoom ............................................................................................................ 70
Live View Strategy ................................................................................................... 71
Target Detection ............................................................................................................... 71
Configure Live View Settings ............................................................................................ 72
Configure Live View Layout .............................................................................................. 72
Configure Auto-Switch of Cameras .................................................................................. 74
Configure Channel-zero Encoding .................................................................................... 74
Using an Auxiliary Monitor............................................................................................... 75
Chapter 6 PTZ Control ................................................................................................................... 76
PTZ Control Wizard ........................................................................................................... 76
Configure PTZ Parameters ................................................................................................ 76
Set PTZ Presets, Patrols & Patterns .................................................................................. 77
Set a Preset ............................................................................................................. 77
Call a Preset ............................................................................................................. 78

HIKVISION DS-7216HGHI-K1 Specifications

General

Product color	Black
Channels quantity	16 channels
Video compression formats	H.264, H.264+, H.265, H.265 Pro+, H.265+
Analog signal format system	NTSC, PAL
DC voltage	12 V
Power consumption (typical)	10 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
BNC input ports	16
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	SATA, SATA II, SATA III
Maximum HDD capacity	10000 GB

Weight and Dimensions

Depth	222 mm
Width	260 mm
Height	45 mm
Weight	1100 g
