HIKVISION DS-7216HGHI-K1 User Manual

Network Video Recorder User Manual
15
Set a Patrol .............................................................................................................. 79
Call a Patrol ............................................................................................................. 80
Set a Pattern ............................................................................................................ 81
Call a Pattern ........................................................................................................... 82
Set Linear Scan Limits .............................................................................................. 82
Call Linear Scan ....................................................................................................... 83
One-touch Park ....................................................................................................... 83
Auxiliary Functions ........................................................................................................... 84
Chapter 7 Storage ............................................................................................................................ 85
Storage Device Management ........................................................................................... 85
Install the HDD ........................................................................................................ 85
Add the Network Disk ............................................................................................. 85
Configure eSATA for Data Storage ........................................................................... 87
Storage Mode ................................................................................................................... 88
Configure HDD Group ............................................................................................. 88
Configure HDD Quota.............................................................................................. 90
Recording Parameters ...................................................................................................... 91
Main Stream ............................................................................................................ 91
Sub-Stream .............................................................................................................. 92
Picture ..................................................................................................................... 92
Configure Advanced Recording Settings ................................................................. 92
Configure Recording Schedule ......................................................................................... 93
Configure Continuous Recording ..................................................................................... 95
Configure Motion Detection Triggered Recording ........................................................... 95
Configure Event Triggered Recording ............................................................................... 96
Configure Alarm Triggered Recording .............................................................................. 96
Configure Picture Capture ................................................................................................ 96
Configure Holiday Recording and Capture ..................................................................... 97
Configure Redundant Recording and Capture ............................................................... 99
Configure 1080p Lite .................................................................................................... 100
Enable the 1080P Lite Mode ............................................................................... 100
Disable the 1080P Lite Mode .............................................................................. 101
Chapter 8 Disk Array .................................................................................................................... 102
Create Disk Array ............................................................................................................ 102
Enable RAID ........................................................................................................... 102

HIKVISION DS-7216HGHI-K1 Specifications

General

Product color	Black
Channels quantity	16 channels
Video compression formats	H.264, H.264+, H.265, H.265 Pro+, H.265+
Analog signal format system	NTSC, PAL
DC voltage	12 V
Power consumption (typical)	10 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
BNC input ports	16
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	SATA, SATA II, SATA III
Maximum HDD capacity	10000 GB

Weight and Dimensions

Depth	222 mm
Width	260 mm
Height	45 mm
Weight	1100 g
