HIKVISION DS-7216HGHI-K1 User Manual

Network Video Recorder User Manual
74
Configure Auto-Switch of Cameras
Purpose:
You can set the auto-switch of cameras to play in different display modes.
Go to System > Live View > General.
Set the video output interface, live view mode and dwell time.
 Video Output Interface: Select the video output interface.
 Live View Mode: Select the display mode for live view, e.g., 2*2, 1*5, etc.
 Dwell Time: The time in seconds to dwell between switching of cameras when enabling auto-
switch. The range is from 5s to 300s.
Go to View to set the view layout.
Click OK to save the settings.
Configure Channel-zero Encoding
Purpose:
You can enable the channel-zero encoding when you need to get a remote view of many channels
in real time from web browser or CMS (Client Management System) software, in order to decrease
the bandwidth requirement without affecting the image quality.
Go to System > Live View > General.
Select the video output interface to Channel-Zero.
Go to System > Live View > Channel-Zero.
Check the checkbox to enable the channel-zero.
Live View- Channel-Zero Encoding
Configure the Frame Rate, Max. Bitrate Mode and Max. Bitrate. The higher frame
rate and bitrate settings result in the higher requirement of bandwidth.

HIKVISION DS-7216HGHI-K1 Specifications

General

Product color	Black
Channels quantity	16 channels
Video compression formats	H.264, H.264+, H.265, H.265 Pro+, H.265+
Analog signal format system	NTSC, PAL
DC voltage	12 V
Power consumption (typical)	10 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
BNC input ports	16
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	SATA, SATA II, SATA III
Maximum HDD capacity	10000 GB

Weight and Dimensions

Depth	222 mm
Width	260 mm
Height	45 mm
Weight	1100 g
