Network Video Recorder User Manual
83
The speed dome starts linear scan from the left limit to the right limit, and you must set the left
limit on the left side of the right limit, as well the angle from the left limit to the right limit
should be no more than 180º.
Call Linear Scan
Before operating this function, make sure the connected camera supports the linear scan and is
in HIKVISION protocol.
Purpose:
Follow the procedure to call the linear scan in the predefined scan range.
Click on the quick settings toolbar in the live view interface..
Click Linear Scan to start the linear scan and click it again to stop it.
(Optional) Click Restore to clear the defined left limit and right limit data.
Reboot the camera to take the settings into effect.
One-touch Park
Before operating this function, make sure the connected camera supports the linear scan and is
in HIKVISION protocol.
Purpose
For some certain model of the speed dome, it can be configured to start a predefined park action
(scan, preset, patrol and etc.) automatically after a period of inactivity (park time).
Click on the quick settings toolbar in the live view interface..
Click Park (Quick Patrol), Park (Patrol 1) or Park (Preset 1) to activate the park action.
Park (Quick Patrol): The dome starts patrol from the predefined preset 1 to preset 32 in
order after the park time. The undefined preset will be skipped.
Park (Patrol 1): The dome starts moving according to the predefined patrol 1 path after the
park time.
Park (Preset 1): The dome moves to the predefined preset 1 location after the park time.
