HIKVISION DS-7216HGHI-K1 User Manual

Network Video Recorder User Manual
189
Two authentication types are selectable: digest and digest/basic. For security reasons, it is
recommended to select digest as the authentication type.
Disable HTTP
Purpose
The admin user account can disable the HTTP service from the GUI or the web browser.
After the HTTP is disabled, all its related services, including the ISAPI, Onvif and Gennetc, will
terminate as well.
Go to System > System Service> System Service.
Uncheck the Enable HTTP to disable the HTTP service.
RTSP Authentication
Purpose
You can specifically secure the stream data of live view by setting the RTSP authentication.
Go to System > System Service> System Service.
RTSP Authentication
Select the authentication type.
Two authentication types are selectable: digest and digest/basic. If you select digest, as the
RTSP authentication, only the request with digest authentication can access the video stream by
the RTSP protocol via the IP address. For security reasons, it is recommended to select digest as
the authentication type.
Click Save to save the settings.
Managing ONVIF User Accounts
Purpose
For the third-party camera connection to the device via ONVIF, you can enable ONVIF function and
manage the user accounts.
Go to System > System Service > ONVIF.

HIKVISION DS-7216HGHI-K1 Specifications

General

Product color	Black
Channels quantity	16 channels
Video compression formats	H.264, H.264+, H.265, H.265 Pro+, H.265+
Analog signal format system	NTSC, PAL
DC voltage	12 V
Power consumption (typical)	10 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
BNC input ports	16
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	SATA, SATA II, SATA III
Maximum HDD capacity	10000 GB

Weight and Dimensions

Depth	222 mm
Width	260 mm
Height	45 mm
Weight	1100 g
