Network Video Recorder User Manual
61
Click Add to finish the adding of the IP camera.
(Optional) Click Continue to Add to continue to add other IP cameras.
Add the Automatically Searched Online IP Cameras
On the IP Camera interface, click the Number of Unadded Online Device to expand
the panel.
Select the automatically searched online devices.
Click Add.
Add IP Camera

If the IP camera to add has not been activated, you can activate it from the IP camera list on
the camera management interface.

For iDS-7200HQHI-K/S and iDS-7200HUHI-K/S series, when IP camera is added, the device
will automatically switch the resolution to WD1/D1 and switch the bit rate to 512 Kbps.
Connecting PoC Cameras
Before you start
 Ensure your device supports PoC (Power over Coaxitron) cameras connection.
 Connect the PoC camera to the DVR.
Purpose
The device will detect the connected PoC cameras automatically, manage the power consumption
via the coaxial communication, and provide power to the cameras via coaxitron.
Step 1 Go to Menu > Camera > PoC Status.
Step 2 Turn on the PoC for the channel(s) as your desire.
Step 3 Check the status of connected PoC camera.

HIKVISION DS-7216HGHI-K1 Specifications

General

Product color	Black
Channels quantity	16 channels
Video compression formats	H.264, H.264+, H.265, H.265 Pro+, H.265+
Analog signal format system	NTSC, PAL
DC voltage	12 V
Power consumption (typical)	10 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
BNC input ports	16
USB 2.0 ports quantity	2
Ethernet LAN	Yes
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	SATA, SATA II, SATA III
Maximum HDD capacity	10000 GB

Weight and Dimensions

Depth	222 mm
Width	260 mm
Height	45 mm
Weight	1100 g
