Network Video Recorder User Manual
66
Chapter 4 Camera Settings
Configure OSD Settings
Purpose:
You can configure the OSD (On-screen Display) settings for the camera, including date/time,
camera name, etc.
Click on the main menu bar.
Click Display.
Select the camera from the drop-down list.
Edit the name in the Camera Name text field.
Check the checkbox of the Display Name, Display Date and Display Week if you want
to show the information on the image.
Set the date format, time format, and display mode.
OSD Configuration Interface
You can use the mouse to click and drag the text frame on the preview window to
adjust the OSD position.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7216HGHI-K1 and is the answer not in the manual?

HIKVISION DS-7216HGHI-K1 Specifications

General IconGeneral
Product colorBlack
Channels quantity16 channels
Video compression formatsH.264, H.264+, H.265, H.265 Pro+, H.265+
Analog signal format systemNTSC, PAL
DC voltage12 V
Power consumption (typical)10 W
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
BNC input ports16
USB 2.0 ports quantity2
Ethernet LANYes
Number of users128 user(s)
Ethernet interface typeFast Ethernet
Supported network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interfaceSATA, SATA II, SATA III
Maximum HDD capacity10000 GB
Weight and Dimensions IconWeight and Dimensions
Depth222 mm
Width260 mm
Height45 mm
Weight1100 g
