Network Video Recorder User Manual
80
Key Point Configuration
1) Configure key point parameters.
Preset: It determines the order at which the PTZ will follow while cycling through the
patrol.
Speed: It defines the speed at which the PTZ will move from one key point to the next.
Duration: It refers to the time span to stay at the corresponding key point.
2) Click Apply to save the key points to the patrol.
(Optional) Click to edit the added key point.
Edit Key Point
(Optional) Select a key point and click to delete it.
(Optional) Click or to adjust the key point order.
Click Apply to save the settings of the patrol.
Repeat steps 3-9 to set more patrols.
Call a Patrol
Purpose:
Calling a patrol makes the PTZ to move according to the predefined patrol path.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7216HGHI-K1 and is the answer not in the manual?

HIKVISION DS-7216HGHI-K1 Specifications

General IconGeneral
Product colorBlack
Channels quantity16 channels
Video compression formatsH.264, H.264+, H.265, H.265 Pro+, H.265+
Analog signal format systemNTSC, PAL
DC voltage12 V
Power consumption (typical)10 W
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
BNC input ports16
USB 2.0 ports quantity2
Ethernet LANYes
Number of users128 user(s)
Ethernet interface typeFast Ethernet
Supported network protocolsTCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interfaceSATA, SATA II, SATA III
Maximum HDD capacity10000 GB
Weight and Dimensions IconWeight and Dimensions
Depth222 mm
Width260 mm
Height45 mm
Weight1100 g
