HIKVISION DS-7316HQHI-K4 User Manual

Digital Video Recorder User Manual
165
Figure 12-2 PPPoE Settings Interface
Step 2 Check the Enable PPPoE checkbox to enable this feature.
Step 3 Enter User Name and Password for PPPoE access.
The User Name and Password should be assigned by your ISP.
Step 4 Click the Apply button to save the settings.
Step 5 After successful settings, the system asks you to reboot the device to enable the new
settings, and the PPPoE dial-up is automatically connected after reboot.
You can go to Menu > Maintenance > System Info > Network interface to view the status of
PPPoE connection.
12.2.2 Configuring Hik-Connect
Purpose
Hik-Connect provides the mobile phone application and the service platform page
(www.hik-connect.com) to access and manage your connected DVR, which enables you to get a
convenient remote access to the surveillance system.
The Hik-Connect can be enabled via operation on SADP software, GUI and Web browser. We
introduce the operation steps on GUI in this section.
Step 1 Go to Menu > Configuration > Network > Platform Access.
Figure 12-3 Hik-Connect Settings
Step 2 Check the Enable checkbox to activate the function.
Then the Service Terms interface pops up as below.

HIKVISION DS-7316HQHI-K4 Specifications

General

Product color	Black
Channels quantity	16 channels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Playback resolutions supported	3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	Serial ATA
Maximum HDD capacity	8000 GB
Number of HDDs supported	4
Power requirements	100 - 240 VAC
Power consumption (typical)	55 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
Dimensions (WxDxH)	445 x 390 x 70 mm
