Digital Video Recorder User Manual
95
Figure 5-32 HDD General- Editing
Step 3 Set the HDD to Read-only.
Step 4 Click OK to save settings and back to the upper level menu.

You cannot save any files in a Read-only HDD. If you want to save files in the HDD, change
the property to R/W.

If there is only one HDD and is set to Read-only, the DVR cannot record any files. Only live
view mode is available.

If you set the HDD to Read-only when the DVR is saving files in it, then the file will be saved
in next R/W HDD. If there is only one HDD, the recording will be stopped.
5.11 One-Key Enabling and Disabling H.264+/H.265+ for
Analog Cameras
Purpose
You can one-key enable or disable H.264+/H.265+ for the analog cameras.
Task 1: One-Key Enabling H.264+/H.265+ for All Analog Cameras
Step 1 Go to Menu > Record > Advanced.
Figure 5-33 Advanced Settings (for HUHI series DVR)
Figure 5-34 Advanced Settings (for HQHI series DVR)

HIKVISION DS-7316HQHI-K4 Specifications

General

Product color	Black
Channels quantity	16 channels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Playback resolutions supported	3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	Serial ATA
Maximum HDD capacity	8000 GB
Number of HDDs supported	4
Power requirements	100 - 240 VAC
Power consumption (typical)	55 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
Dimensions (WxDxH)	445 x 390 x 70 mm
