Digital Video Recorder User Manual
96
Step 2 Click Enable to enable H.264+/H.265+ for all the analog cameras and the following
attention box pops up.
Figure 5-35 Attention Box
Step 3 Click Yes to enable the function and reboot the device to have new settings taken effect.
Task 2: One-Key Disabling H.264+/H.265+ for All Analog Cameras
Step 1 Go to Menu > Record > Advanced.
Step 2 Click Disable to disable H.264+ for all the analog cameras and the following attention box
pops up.
Figure 5-36 Attention Box
Step 3 Click Yes to enable the function and reboot the device to have new settings taken effect.
5.12 Configuring 1080P Lite
Purpose
When the 1080P Lite Mode is enabled, the encoding resolution at 1080P Lite (real-time) is
supported. If not, up to 1080P (non-real-time) is supported.
This chapter is appplicable to HQHI series DVR.
Task 1: Enabling the 1080P Lite Mode
Step 1 Go to Menu > Record > Advanced.
Figure 5-37 Advanced Interface
Step 2 Check the checkbox of 1080P Lite Mode and click Apply to pop up the attention box. After
enabling 1080p lite mode, the 3 MP signal is not accessible to analog channel.

HIKVISION DS-7316HQHI-K4 Specifications

General

Product color	Black
Channels quantity	16 channels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Playback resolutions supported	3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	Serial ATA
Maximum HDD capacity	8000 GB
Number of HDDs supported	4
Power requirements	100 - 240 VAC
Power consumption (typical)	55 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
Dimensions (WxDxH)	445 x 390 x 70 mm
