HIKVISION DS-7316HQHI-K4

Digital Video Recorder User Manual
226
Model
DS-7204HUHI-K1
DS-7208HUHI-K1
Working
humidity
10% to 90%
Dimensions
(W × D × H)
315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch)
Weight
(without
HDD)
≤ 1.16 kg (2.6 lb)
≤ 2 kg (4.4 lb)
17.1.5 DS-7200HUHI-K2
Model
DS-7204HUHI-K2
DS-7208HUHI-K2
DS-7216HUHI-K2
Video/Audio
input
Video
compression
H.265+/H.265/H.264+/H.264
Analog video
input
4-ch
8-ch
16-ch
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection
HDTVI input
5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30,
720p25
AHD input
1080p25, 1080p30, 720p25, 720p30
HDCVI input
1080p25, 1080p30, 720p25, 720p30
CVBS input
PAL/NTSC
IP video input
2-ch
Up to 6 MP resolution
Supports H.265+/H.265/H.264+/H.264 IP cameras
Audio
compression
G.711u
Audio input
4-ch, RCA (2.0 Vp-p, 1 KΩ)
Video/Audio
output
CVBS output
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 ×
480
