HIKVISION DS-7316HQHI-K4 User Manual

Digital Video Recorder User Manual
233
Model
DS-7204HUHI-K1/P
DS-7208HUHI-K2/P
Synchronous
playback
4-ch
8-ch
Network
management
Remote
connections
128
Network
protocols
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS,
iSCSI, UPnP™, HTTPS, ONVIF
Hard disk
SATA
1 SATA interface
2 SATA interfaces
Capacity
Up to 8 TB capacity for each disk
External
interface
Two-way
audio input
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input)
Network
interface
1, RJ45 10M/100M
self-adaptive Ethernet interface
1, RJ45 10M/100M/1000M
self-adaptive Ethernet interface
USB interface
2 × USB 2.0
Front panel: 1 × USB 2.0
Rear panel: 1 × USB 3.0
Serial
interface
RS-485 (half-duplex)
Alarm in/out
4/1
8/4
General
Power supply
48 VDC
Consumption
(without
HDD)
≤ 15 W
≤ 20 W
Working
temperature
-10 ºC to +55 ºC (+14 ºF to +131 ºF)
Working
humidity
10% to 90%
Dimensions
(W × D × H)
315 × 242 × 45 mm (12.4 × 9.5 ×
1.8 inch)
380 × 320 × 48 mm (15.0 × 12.6
× 1.9 inch)
Weight
(without
HDD)
≤ 1.5 kg (3.3 lb)
≤ 2 kg (4.4 lb)

HIKVISION DS-7316HQHI-K4 Specifications

General

Product color	Black
Channels quantity	16 channels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Playback resolutions supported	3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
HDD interface	Serial ATA
Maximum HDD capacity	8000 GB
Number of HDDs supported	4
Power requirements	100 - 240 VAC
Power consumption (typical)	55 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	5000 g
Dimensions (WxDxH)	445 x 390 x 70 mm
