HIKVISION DS-KD7003EY-IME2

Table 7-1 Door Open Duraon
Rotary DIP Switch Door Open Duraon(s)
0 2
1 1
2 3
3 4
4 5
5 8
6 10
7/8/9 Reserved
Note
●
It is recommended to sck the supplied number remark on the back of the device to indicate the
device's No.
DIP Switch of Indoor Staon
Use the rotary DIP switch to set the indoor extension No., the building No., and the room No. The
Tens column refers to the number in Tens, and the Units column refers to the number in Units. On
each rotary DIP switch, 0 to 9 refers to No. 0 to 9. In total, you can use 1 to 3 to number the indoor
extension No., and use 1 to 99 to number the building or the room. Use the screwdriver to adjust
the number. The arrow indicates the number. An example is shown below.
Figure 7-4 Example: DIP Switch of Indoor Staon
DS-KD7003EY-IME2 Module Door Staon User Manual
50
