Set I/O Parameters

You can set I/O Parameters on PC Web.

Steps

Click Conguraon → Video Intercom → I/O Sengs .

Select Input 2 as Disable or Door Status. Select Input 3 and Input 4 as Disable or Exit

Buon.

Note

The Input 1 is Door Status by default.

Select Output 2 as Disable, Mechanical Doorbell or Electric Lock.

Note

The Output 1 is Electric Lock by default.

Sub Module Conguraon

Steps

Click Intercom → Sub Module

Conguraon , and you can view the sub module informaon,

including No., module type, status, and version.

Click to edit the sub module.

Display Module

●

Slide to adjust Screen Backlight Brightness.

●

Slide Enable Buzzer to enable the

funcon.

Touch Screen Module

●

Adjust Screen Backlight Brightness.

●

Slide Enable Buzzer to enable the

funcon.

●

Select Default Home Page which will be displayed on the screen of the module.

PMR Module

Click to enable power consumpon selecon.

You can select 8 W, 6 W or 4 W for the PMR Module.

Note

If the system power goes o, an external power supply of 12 V, 2 A for the main unit is

necessary.

DS-KD8003 Series Module Door Staon User Manual

100
