HIKVISION DS-KD8003 Series User Manual

Note
●
It takes two three-module mounng frames. The dimension of three-module mounng frame
(W × H × D) is: 320.8 mm × 107 mm × 32.7 mm.
●
The dimensions above are for reference only. The actual size can be slightly dierent from the
theorecal dimension.
Steps
1.
Paste two
Scker 1 onto the wall. Make sure the sckers are placed horizontally via measuring
with the gradienter.
2.
Drill 8 holes according to the screw holes on the scker.
Note
●
The suggested size of hole is 6 (diameter) × 25 (depth) mm.
●
The suggested length of cables le outside is 270 mm.
3.
Pull out the cable through the cable hole of the le scker.
DS-KD8003 Series Module Door Staon User Manual
54
