Figure 4-60 Cables Connecon
Note
●
Cable 2,3,5 and 6 are the module-connecng lines (190 mm) in the package.
●
Cable 4 is the module-connecng line (400 mm) in the package.
●
Main unit must be put in the top grid.
10.
Pull the grounding line out and xed its two end to the screw on the cover.
