HIKVISION HWN Series User Manual

Network Video Recorder User Manual
2
What to do next
Follow the wizard to set basic parameters.
● When you forget your password, there are three methods to reset it, including password
resetting email, Hik-Connect, and security questions. You have to configure at least one
password resetting method. Refer to Set Password Resetting Email and Hik-Connect for details.
● For unlock pattern. Refer to Set Unlock Pattern for details.
● For general system parameters. Refer to General for details.
● For general network parameters. Refer to General for details.
● For storage device configuration. Refer to Storage Device for details.
● For adding network cameras. Refer to Network Camera for details.
● For platform configuration. Refer Hik-Connect to for details.
1.2 Login
1.2.1 Set Unlock Pattern
Admin user can use the unlock pattern to login. You can configure the unlock pattern after the
device is activated.
Steps
1. Use the mouse to draw a pattern among the 9 dots on the screen. Release the mouse when the
pattern is done.
Note
● The pattern shall have 4 dots at least.
● Each dot can be connected for once only.
2. Draw the same pattern again to confirm it.
Figure 1-2 Set Unlock Pattern
When the two patterns match, the pattern is configured successfully.

HIKVISION HWN Series Specifications

General

Model Series	HWN Series
Video Input	IP Video Input
Video Output	HDMI, VGA
Operating System	Embedded Linux
Type	NVR
Channels	Varies by model (4/8/16/32/64)
Recording Resolution	Up to 12MP
Resolution	Varies by model
Hard Drive Support	Yes
HDD Slots	Varies by model (1/2/4/8)
Max HDD Capacity	Up to 10TB per HDD
Network Interface	RJ45 10/100/1000Mbps
USB Interface	USB 2.0, USB 3.0
Operating Temperature	-10°C to +55°C (14°F to 131°F)
Operating Humidity	10% to 90%
Dimensions	Varies by model
Weight	Varies by model
Category	Network Video Recorder (NVR)
Power Supply	12 VDC
