HIKVISION HWN Series User Manual

Network Video Recorder User Manual
69
Figure 6-27 Recording Schedule
Continuous
Continuous recording.
Event
Recording triggered by all event triggered alarms.
2. Select a camera in Camera No.
3. Turn on Enable.
4. Configure the recording schedule.
1) Click Edit.
2) Select a day to configure in Weekday.
3) To set an all-day recording schedule, check All Day and select schedule Type.
4) To set other schedules, uncheck All Day and set Start/End time and schedule Type.
Note
Up to 8 periods can be configured for each day. And the time periods cannot be overlapped
with each other.
5) Click OK to save the settings and go back to upper level menu.
Note
You can also select schedule type as Continuous or Event, and drag the cursor on the desired
period to draw a colored bar.
5. Click Advanced to set advanced parameters.
Record Audio
Audio will be record to the video file.
Pre-Record
The time you set to record before the scheduled time or event. For example, when an alarm

HIKVISION HWN Series Specifications

General

Model Series	HWN Series
Video Input	IP Video Input
Video Output	HDMI, VGA
Operating System	Embedded Linux
Type	NVR
Channels	Varies by model (4/8/16/32/64)
Recording Resolution	Up to 12MP
Resolution	Varies by model
Hard Drive Support	Yes
HDD Slots	Varies by model (1/2/4/8)
Max HDD Capacity	Up to 10TB per HDD
Network Interface	RJ45 10/100/1000Mbps
USB Interface	USB 2.0, USB 3.0
Operating Temperature	-10°C to +55°C (14°F to 131°F)
Operating Humidity	10% to 90%
Dimensions	Varies by model
Weight	Varies by model
Category	Network Video Recorder (NVR)
Power Supply	12 VDC
