Figure 4-7 Special Preset
You may need to use the OSD (On Screen Display) menu when controlling
the speed dome remotely. To display the OSD menu on the live view screen,
you can call the preset number 95.
4.5.3 Setting / Calling a Patrol
Purpose:
A patrol is a memorized series of preset function. It can be configured and called on
the patrol settings interface. There are up to 8 patrols for customizing. A patrol can
be configured with 32 presets.
Before you start:
Please make sure that the presets you want to add into a patrol have been defined.
Setting a Patrol:
Steps:
1. In the PTZ control panel, click to enter the patrol settings interface.
2. Select a patrol number from .
3. Click to enter the adding interface of preset, as shown in Figure 4-8.
Figure 4-8 Adding Presets
