This function varies depending on the models of speed dome.
Capture Mode:
You can set the Capture Mode to OFF, 1280*720@25fps, and 1280*960@25fps.
Other
Lens Initialization
The lens operates the movements for initialization when you check the check box of
Lens Initialization.
Zoom Limit
You can set Zoom Limit value to limit the maximum value of zooming. The value can
be set to 20, 40, 80, 160 and 320.
This function varies depending on the models of speed dome.
Local Output
You can enable or disable the video output through the CVBS interface on your
demand.
6.5.2 Configuring OSD Settings
Purpose:
The speed dome supports following on screen displays:
Zoom: Identifies the amount of magnification.
Direction: Displays panning and tilting direction, with the format of PXXX TXXX. The
XXX following P indicates the degrees in pan direction, while the XXX following T
indicates the degrees in tilt position.
Time: Supports for time display.
Preset Title: Identifies preset being called.
Camera Name: Identifies the name of speed dome.
You can customize the on screen display of time.
Steps:
1. Enter the OSD Settings interface:
Configuration > Advanced Configuration > Image > OSD Settings
