6.6.13 Region Exiting Detection
Purpose:
Region exiting detection function detects people, vehicle or other objects which exit
from a pre-defined virtual region, and some certain actions can be taken when the
alarm is triggered.
Steps:
1. Enter the Region Exiting Detection settings interface:
Configuration> Advanced Configuration> Smart Event> Region Exiting
Detection
2. Check the checkbox of Enable Region Exiting Detection to enable the function.
Figure 6-61 Configuring Region Exiting Detection
3. Select the region from the dropdown list for detection settings.
4. Click the button to start the region drawing.
5. Click on the live video to specify the four vertexes of the detection region, and
right click to complete drawing.
Repeat the step to configure other regions. Up to 4 regions can be set. You can
click the button to clear all pre-defined regions.
6. Click the button to set the arming schedule. Refer to Step 2 in
Section 6.6.1 Configuring Motion Detection.
7. Select the linkage methods for region exiting detection, including Notify
Surveillance Center, Send Email, Upload to FTP, Trigger Channel and Trigger
Alarm Output. Please refer to Step 3 in Section 6.6.1 Configuring Motion
Detection.
8. Click button to save the settings.
