10.1.3 Machine Frame and Traction System
PN Description
426460 FRONT WHEEL D=8.8 L=2.6
426305 REAR WHEEL D=4 L=1
Carbon Brushes
409413 TRACTION MOTOR CAR.BR.
10.2 Recommended Spare Parts
The following table refers to the Recommended Spare Parts, and reports the amount suggested by
the number of purchased machines.
Machines Parts
1 ⇒ 1
10 ⇒ 2
25 ⇒ 3
50 ⇒ 4
10.2.1 Electrical System
PN Description
436434 CHARGER NE284-F 24V 15A
227019 KEY (NO HFM)
227287 KEY (HFM)
409491 KEY MICROSWITCH
409491 SAFETY MICROSWITCH 10A 3X22 C/ROTEL
446355 POTENTIOMETER
409499 SQUEEGEE MICROSWITCH 3X22 L.C.
446651 MAIN BOARD 7CFCP002
437945 ACTUATOR CONTROL SLOT
446674 DISPLAY 7TFT5002 TOUCH SCREEN 5”
446359 HANDLE BUTTON BOARD 7CFCT020
60
