F30 01 3 Product Description
HI 800 145 E Rev. 2.00 Page 23 of 52
3.4.2.2 Network Ports Used for Ethernet Communication
UDP ports Use
8000 Programming and operation with the programing tool
8001 Configuration of the remote I/O using the PES (ELOP II Factory)
8004 Configuration of the remote I/O using the PES (SILworX)
6010 safeethernet and OPC
123
SNTP (time synchronization between PES and remote I/O, PES and
external devices)
6005 / 6012 If TCS_DIRECT was not selected in the HH network
502 Modbus (can be modified by the user)
44 818 EtherNet/IP session protocol for device identification
2222 EtherNet/IP data exchange
Table 13: Network Ports (UDP Ports) in Use
TCP ports Use
502 Modbus (can be modified by the user)
xxx TCP SR assigned by the user
44 818 EtherNet/IP explicit messaging services
Table 14: Network Ports (TCP Ports) in Use
3.4.2.3 Connections for Fieldbus Communication
The three 9-pole D-sub connectors are located on the front plate of the housing.
The fieldbus interfaces FB1 and FB2 can be equipped with fieldbus submodules. The fieldbus
submodules are optional and must be mounted by the manufacturer. The available fieldbus
submodules are described in the SILworX communication manual (HI 801 101 E).
The fieldbus interfaces are not operational without fieldbus submodule.
Factory-made, the fieldbus interface FB3 is equipped with RS485 for Modbus (master or slave)
or ComUserTask.
