HIMA HIMatrix F30 011 User Manual

F30 01 Table of Contents
HI 800 145 E Rev. 2.00 Page 3 of 52
Table of Contents
1
Introduction 5
1.1 Structure and Use of this Manual 5
1.2 Target Audience 6
1.3 Formatting Conventions 7
1.3.1 Safety Notes 7
1.3.2 Operating Tips 8
2 Safety 9
2.1 Intended Use 9
2.1.1 Environmental Requirements 9
2.1.2 ESD Protective Measures 9
2.2 Residual Risk 10
2.3 Safety Precautions 10
2.4 Emergency Information 10
3 Product Description 11
3.1 Safety Function 11
3.1.1 Safety-Related Digital Inputs 11
3.1.1.1 Reaction in the Event of a Fault 12
3.1.1.2 Line Control 12
3.1.2 Safety-Related Digital Outputs 13
3.1.2.1 Reaction in the Event of a Fault 14
3.2 Equipment, Scope of Delivery 15
3.2.1 IP Address and System ID (SRS) 15
3.3 Type Label 16
3.4 Structure 17
3.4.1 LED Indicators 18
3.4.1.1 Operating Voltage LED 18
3.4.1.2 System LEDs 19
3.4.1.3 Communication LEDs 21
3.4.1.4 I/O LEDs 21
3.4.1.5 Fieldbus LEDs 21
3.4.2 Communication 22
3.4.2.1 Connections for Ethernet Communication 22
3.4.2.2 Network Ports Used for Ethernet Communication 23
3.4.2.3 Connections for Fieldbus Communication 23
3.4.3 Reset Key 24
3.4.4 Hardware Clock 24
3.5 Product Data 25
3.5.1 Product Data F30 011 (-20 °C) 26
3.5.2 Product Data F30 014 26
3.6 Certified HIMatrix F30 27

HIMA HIMatrix F30 011 Specifications

General

Brand	HIMA
Model	HIMatrix F30 011
Category	Controller
Language	English
