HIMA HIMatrix F30 Safety Manual

HIMatrix 8 Safety-related Aspects of the User Program
HI 800 023 E Rev. 1.01 Page 51 of 72
System Parameters of the Resource - Versions Prior to 7
Switch Function
Default
value
Setting for
safe operation
Main enable
The following switches/parameters can
be changed during operation (= RUN)
using the PADT.
ON OFF
1)
Autostart
Automatic start after powering on the
controller.
OFF ON / OFF
2)
Start/Restart
allowed
Cold start, warm start or hot start with
PADT in RUN or STOP.
ON OFF
1)
Load allowed Load enable for a user program. ON ON
Test mode
allowed
The test mode is permitted or not for the
user program.
During the test mode, the program
processing is frozen. The outputs re-
main active and the program processing
can be continued in single steps.
OFF OFF
Changing the
variables in the
OLT allowed
The values of variables can be visual-
ized and modified in the online test
(OLT) fields of the logic.
OFF OFF
3)
Forcing al-
lowed
Entering and activating values for the
PES variables/signals are allowed, irre-
spective of the current value of the
process or logic signal.
OFF
Defined by the
test institute.
Stop at Force
Timeout
It stops the CPU upon expiration of the
force time.
ON
Defined by the
test institute.
1)
In the RUN state, it is only possible to switch to the OFF value.
2)
The setting ON or OFF depends on the application.
3)
In the RUN state, it is only possible to switch to ON.
Table 28: System Parameters of the CPU
For forcing, additional switches and parameters can be preset.
Hardware System Variables - Versions Beyond 7
These variables are used to change the behavior of the controller while it is operating in
specific states. These variables can be set in the hardware Detail View located in the
SILworX Hardware Editor.
Variable Function
Default
setting
Setting for
safe operation
Force Deactivation
Used to prevent forcing and to stop it imme-
diately
OFF Application-specific
Spare 0 ... Spare 16 No function - -
Emergency Stop 1 ...
Emergency Stop 4
Emergency stop switch to shut down the
controller if faults are detected by the user
program
OFF Application-specific
Read-only in RUN
After starting the controller, no operating
action such as stop, start or download is
permitted in SILworX , except for forcing and
reload.
OFF Application-specific
Reload Deactivation Prevents execution of reload OFF Application-specific
Table 29: Hardware System Variables
