HIMA HIMatrix F30 Safety Manual

2 Intended Use HIMatrix
Page 12 of 72 HI 800 023 E Rev. 1.01
2.3.3 EMC Requirements
Higher interference levels are required for safety-related systems. HIMatrix systems meet
these requirements in accordance with IEC 62061 and IEC 61326-3-1 (DIS). See column
"Criterion FS“ (Functional Safety).
IEC/EN 61131-2 Interference immunity tests
Criterion
FS
IEC/EN 61000-4-2 ESD test: 6 kV contact, 8 kV air discharge -
IEC/EN 61000-4-3 RFI test (10 V/m): 26 MHz...1 GHz, 80 % AM
RFI test (20 V/m): 26 MHz...2.7 GHz, 80 % AM: EN
298
-
20 V/m
IEC/EN 61000-4-4 Burst test: 2 kV power supply-, 1 kV signal lines 4 kV
IEC/EN 61000-4-12 Damped oscillatory wave test
2.5 kV L-,L+ / PE
1 kV L+ / L -
Table 6: Interference Immunity Tests
IEC/EN 61000-6-2 Interference immunity tests
Criterion
FS
IEC/EN 61000-4-6 High frequency, asymmetrical
10 V, 150 kHz...80 MHz, AM
20 V, 150 kHz...80 MHz, AM: EN 298
20 V
IEC/EN 61000-4-3 900 MHz pulses
IEC/EN 61000-4-5 Surge: 2 kV, 1 kV 2 kV /
1 kV
Table 7: Interference Immunity Tests
IEC/EN 61000-6-4 Noise emission tests
EN 55011
Class A
Emission test:
radiated, conducted
Table 8: Noise Emission Tests
2.3.4 Power Supply
The following table lists the key tests and thresholds for the HIMatrix systems' power
supply:
IEC/EN 61131-2 Review of the DC supply characteristics
The power supply must comply with the following standards:
IEC/EN 61131-2:
SELV (Safety Extra Low Voltage) or
PELV (Protective Extra Low Voltage)
HIMatrix systems must be fuse protected as specified in this manual
Voltage range test:
24 VDC, -20 %...+25 % (19.2 V...30.0 V)
Momentary external current interruption immunity test:
DC, PS 2: 10 ms
Reversal of DC power supply polarity test:
Refer to corresponding chapter of the system manual or data sheet of
power supply.
Table 9: Review of the DC Supply Characteristics
