7.6 Message Reference
142
7.6.4 Command Compatibility with the Model 3560 AC
mΩ HiTESTER
Model 3561 and 3561-01 BATTERY HiTESTERs accept all of the
commands supported by the HIOKI 3560 AC mΩ HiTESTER.
However the following differences result from the functional
differences.
Comparator Tables
Up to 30 comparator settings can be saved with the Model 3560. The
settings of each table can be changed directly by specifying the table
number.
With this instrument, up to 126 measurement configurations (including
comparator settings) can be saved (Panel Save). Settings for each
configuration cannot be set directly. To recall saved configuration
settings, specify the table (panel) number and execute Panel Load. A
table number does not need to be specified for comparator settings.
Comparator Operations
Model 3560 judges resistance and voltage measurements together as
PASS/FAIL.
This instrument judges resistance and voltage independently. Also,
when the Comparator function is enabled (ON), auto-ranging is
disabled (OFF).
Voltage Limiter
This instrument does not include a voltage limiter function (limiting
open-terminal voltage to 20 mV). This instrument’s open-terminal
voltage is 7 V peak dropping to a few millivolts when the test leads are
connected to a test object.
Sense Line Disconnect Detection
The sense line disconnect detection function cannot be switched on/
off with this instrument. Detection is always enabled.
Resistance Value Digits with FAST Sampling
When FAST sampling is enabled on Model 3560, the number of
resistance measurement digits is decreased from five to four.
With this instrument, measurement values are always five digits
(31,000 counts) regardless of sampling rate.
Voltage Measurement
Model 3560 provides 5 and 50 V ranges, with five-digit (50,000 count)
measurement values.
This instrument provide one 20 V range with six-digit measurement
values (up to 20.0000 V, one digit more than Model 3560).
