8.1 Basic Specifications
160
Panel Save
Panel save function Measurement configurations can be saved and reloaded by
specifying a Panel number
No. of panel to save
126
Saved settings Measurement mode, Resistance measurement range, Auto-ranging
setting, Zero-adjust on/off setting and value, Sampling rate,
Switching display setting, Trigger source, Delay setting, Averaging
setting, Comparator setting, Statistical calculation setting and Key-
lock setting
Reset
Reset
Reset/ System reset
* System Reset also initializes Panel Save data
Display Device
Display device
LED
External Interfaces
EXT I/O Input : CMOS level
Output : Open collector, 35 V, 50 mA max.
Input signals : Measurement start trigger, print, zero-adjustment,
calibration, manual comparator and panel load (7
bit)
Output signals : End-of-measurement, End measurement,
Comparator result (resistance Hi/ IN/ Lo, voltage
Hi/ IN/ L, AND), measurement fault and General-
Purpose output (10 bit)
* EXT I/O control (input) can be disabled by a remote command
RS-232C Communications settings:
Data length (8 bit), stop bit (1 bit), parity (none)
Baud rate : 9600 bps/ 19200 bps/ 38400 bps
Flow control : none
Printer Output to printer via RS-232C (multi-use)
Printer : Model 9670 (option)
Communications settings:
Data length (8 bit), stop bit (1 bit), parity (none)
Baud rate : 9600 bps
GP-IB
(Model 3561-01 only)
Applicable GP-IB Standards: IEEE488.2
Address : 0 to 30
Delimiter : LF/ CR+LF
