6.4 Printing
86
Example Printouts _____________________________________________
Statistical Calculations (Comparator ON)
*** RESISTANCE ***
Number 85
Valid 85
Average 13.06mOhm
Max 13.78mOhm( 74)
Min 12.10mOhm( 3)
Sn 0.38mOhm
Sn-1 0.38mOhm
Cp 1.32
CpK 0.09
Comp Hi 40
Comp IN 45
Comp Lo 0
*** VOLTAGE ***
Number 85
Valid 85
Average 10.0074 V
Max 10.0197 V ( 57)
Min 9.9938 V ( 31)
Sn 0.0068 V
Sn-1 0.0068 V
Cp 0.35
CpK 0.32
Comp Hi 10
Comp IN 59
Comp Lo 16
Measurement values
(V mode)
3132 4.2019 V
3133 15.2084 V
Measurement values
(ΩV mode)
1 298.60mOhm, 1.3924 V
2 0.2984 Ohm, 1.3924 V
3 - 3.35mOhm, 0.0000 V
4 - 0.0054 Ohm, 0.0000 V
5 299.10mOhm,- 1.3923 V
6 0.2984 Ohm,- 1.3923 V
7 3.57mOhm, 13.9071 V
8 - 16.89mOhm,-13.9088 V
Measurement values
(Ω mode)
15 209.98mOhm
16 0.2103 Ohm
With erroneous measurement values
10 O.F. , O.F.
11 - O.F. ,- O.F.
12 -------- ,--------
13 Invalid , Invalid
14 O.F. , 12.0097 V
15 - 19.82mOhm,- O.F.
With the Comparator ON
95 105.80mOhm Lo, 0.0000 V IN
96 213.15mOhm Hi
97 213.12mOhm IN
98 213.11mOhm Lo
99 10.0072 V Hi
100 10.0071 V IN
101 10.0070 V Lo
102 O.F. Hi, O.F. Hi
103 - 3.11mOhm Lo,- O.F. Lo
104 -------- --,-------- --
With the relative value comparison method
(reference value and tolerance)
84 0.023 % Hi, 0.001 % IN
85 0.014 % IN, 0.000 % IN
86 - 0.019 % Lo, 0.002 % IN
Interval print
00:00:00 13.74mOhm, 10.0138 V
00:00:01 13.87mOhm, 10.0138 V
00:00:02 13.67mOhm, 10.0139 V
00:00:03 13.47mOhm, 10.0138 V
00:00:04 13.58mOhm, 10.0139 V
00:00:05 13.58mOhm, 10.0139 V
00:00:06 13.68mOhm, 10.0139 V
Max/Min count
Measurement values indicated as "Invalid" cannot be displayed by
the instrument.
The number of statistical calculation results indicated as “Valid”
equals the count of valid data excluding measurement faults and
overflows.
