7.6 Message Reference
144
:CSET:RPARameter
:CSET:RPARameter?
<Upper threshold/ Lower
threshold>
Setting range: 0 to 3.1000E+0
(only valid within 300 mΩ and 3
Ω ranges)
Setting range: 0 to 3.1000E+3
:CSET:RRANge
:CSET:RRANge?
0 to 3E+0
300E-3/ 3E+0
Resistance range: 0 to 3.1E+0
(Although not an error,
measurements are valid only
within the provided 300 mΩ
and 3 Ω ranges)
Resistance range: 0 to 3.1E+3
:CSET:VPARameter
:CSET:VPARameter?
<Upper threshold/ Lower
threshold>
Setting range:
0 to 50.0000 (20 V range)
* Negative setting values are
invalid.
Setting range:
-5.0000 to 5.0000
(5 V range)
-50.000 to 50.000
(50 V range)
:CSET:VRANge
:CSET:VRANge?
-50 to 50
20E+0
Voltage range: -20 to 20
(Although not an error,
measurements are valid only
Response: 20E+0
Voltage range: -50 to 50
Response: 5E+0/ 50E+0
:CTMode
:CTMode?
AUTo/ MANual
:MEASure:BATTery?
<Measured resistance,
Measured voltage,
Judgment result>
FAIL/ PASS/ OFF/ NG
Resistance measurement
values consist of five digits
with FAST sampling
* Numerical values do not
include a decimal point.
Resistance measurement
values consist of four digits
with FAST sampling
* Numerical values do not
include a decimal point.
:MEASure:RESistance?
<Measured resistance,
Judgment result> FAIL/
PASS/ OFF/ NG (ΩV)
HI/ IN/ LO/ OFF/ NG (Ω)
Resistance measurement
values consist of five digits
with FAST sampling
* Numerical values do not
include a decimal point.
Resistance measurement
values consist of four digits
with FAST sampling
* Numerical values do not
include a decimal point.
:MEASure:VOLTage?
<Measured voltage,
Judgment result> FAIL/
PASS/ OFF/ NG
Response:
Mark: one character + six
numerals
(20.0000 V range)
* Numerical values do not
include a decimal point.
Response:
* Numerical values do not
include a decimal point.
:FREQuency
:FREQuency?
50/60
:LOCK:KEY
:LOCK:KEY?
ON/OFF
:HEADer
:HEADer?
ON/OFF
:LOCK:EXTernal
:LOCK:EXTernal?
ON/OFF
:CSET:BEEPer
:CSET:BEEPer?
OFF/ PASS/ FAIL (ΩV)
OFF/ IN/ HL (Ω)
:HOLD
:HOLD?
ON/ OFF
:LIMit
:LIMit?
ON/ OFF (function not available) Open terminal voltage is
limited to 20 mV
:SENSecheck
:SENSecheck?
ON/ OFF (function not available) Sense line disconnect
detection is provided
:ZERoclear
Message ([ ] = optional) Data Contents
( ) = response data
Differences
Model 3561 (3561-01) Model 3560
