37
9.5 Kolben wieder einbauen
Achtung!
Kolben vorsichtig in den Glaszylinder einstecken,
da sonst die Dichtlippe beschädigt werden könnte.
Dies hätte eine Undichtigkeit des Systems zur Folge!
- Funktion des Gerätes prüfen.
9.6 Ansaug-/Ausstoß- und
Rückführventil festdrehen
- Ansaugventil mit Montageschlüssel im
Uhrzeigersinn festdrehen.
- Ausstoßventil mit Montageschlüssel im
Uhrzeigersinn festdrehen.
- Rückführventil mit Montageschlüssel im
Uhrzeigersinn festdrehen.
9.5 How to reassemble the piston
Please note:
Carefully insert piston into the glass cylinder so that
sealing lips will not be damaged. A damaged sealing
lip will cause leakage problems!
- Verify proper functioning of the device.
9.6 How to secure suction,
discharge and recirculation valve
- Tighten suction valve clockwise with
wrench.
- Tighten discharge valve clockwise with
wrench.
- Tighten recirculation valve clockwise
with wrench.
- 37 -
Please note:
Carefully insert piston into the glass cylinder so that
sealing lips will not be damaged. A damaged sea-
ling lip will cause leakage problems!
- Verify proper functioning of the device.
9.6 How to Secure Suction,
Discharge and Recirculation Valve
- Tighten suction valve clockwise with
wrench.
- Tighten discharge valve clockwise with
wrench.
- Tighten recirculation valve clockwise
with wrench.
Achtung!
Kolben vorsichtig in den Glaszylinder einstecken,
da sonst die Dichtlippe beschädigt werden könnte.
Dies hätte eine Undichtigkeit des Systems zur Folge!
- Funktion des Gerätes prüfen.
9.6 Ansaug-/Ausstoß- und
Rückführventil festdrehen
- Ansaugventil mit Montageschlüssel im
Uhrzeigersinn festdrehen.
- Ausstoßventil mit Montageschlüssel im
Uhrzeigersinn festdrehen.
- Rückführventil mit Montageschlüssel im
Uhrzeigersinn festdrehen.
