Periodic Maintenance and Adjustment 8-13
Cleaning Spark Arrestor
1. Locate and remove the 3 bolts (1)
holding the spark arrestor in place on
back of the muffler.
Spark Arrestor bolts
2. Remove spark arrestor(2) from muffler.
3. Gently tap the spark arrestor on a hard
surface to remove sediment.
4. Use a wire brush to loosen and remove
any additional sediment (2).
① Exhaust Outlet ② Spark arrestor
4. Re-install the spark arrestor
5. Re-installl the 3 bolts (1) that hold the
spark arrestor in place.
