Hitachi C 10FCD Instruction Manual And Safety Instructions

13
English
Fig. 9
Fig. 10
Fig. 12
BEFORE CUT TING
1. Cutting a groove on the table insert.
A groove has to be cut in the table insert, before starting
operation. Secure a piece of w ood about 5-1/8" (130 m m)
wide to the table with the vise assem bly, to prevent the
breakage of the table insert.
After the switch has been turned on and the sa w blade has
reached m aximu m speed, slowly lo wer the handle to cut a
groove on the table insert.
CAUTION: Do n o t c ut t h e groove too quickly;
otherwise the table insert might become
damaged.
2. Checking the saw blade lower limit position
WARNING: To prevent an accident or personal injury, always turn off the trigger switch and
disconnect the power plug from the rece ptacle before adjustment.
Check that the saw blade can be lo wered 1-1/32" to 1-3/32" (26 m m to
28 m m) below the table insert.
If necessary, adjust as follows:
(1) Loosen the 6 m m lock nut on the 6 m m depth adjustment screw.
(2) Turn the 6 m m depth adjustm ent screw as necessary to set the lower
li m it position. T he sa w blad e g oes u p wh en the 6 m m de pth
adjustm ent scre w is turned clockwise and dow n w hen it is turned
counterclockwise.
(3) O nce the adjustm ent is com plete, fully tighten the 6 m m lock nut.
NOTE: Before tightening the 6 mm lock nut, confirm that the saw
blade i s adjusted so that it will not cut into the table.
3. O blique angle
Before the power tool is shipped fro m the factory, it is adjusted for 0°, right angle, left 45° bevel cutting
angle and right 45° bevel cutting angle with the 6 m m bolt (A), 6 m m bolt (B) and the 5 m m hex. soc. hd. cap
bolt (C) (see Fig. 7).
When changing the adjustm ent, change the height of the 6 m m bolt (A), 6 m m bolt (B) or the 5 m m hex. soc.
hd. cap bolt (C) (see Fig. 7) by turning them.
(Maximum bevel cutting angle is 45°).
When changing the bevel angle to the right 45° , pull up the locating bar on the direction sho wn in Fig. 12
and incline the m otor head to the right.
When adjusting the m otor head to 0°, always return the locating bar to its initial position.
Table Insert
Table
d
6 m m Depth
Adjust m ent
Scre w
6 m m Lock
Nut
Fig. 11
6 m m Bolt (A)
(Sto p per for right 45° bevel angle)
Locating
Bar
Cla mp Lever
Indicator
Be vel A ngle
Scale
6 m m Bolt (B)
(Sto p per for left 45°
bev el angle)
5 m m Hex. soc. hd. cap bolt (C)
(Sto p per for 0°)
Locating
Bar
Pull
Up
Clam p
Lever
